LED Chip Brand : philips/Bridgelux/
Input Volage : AC100-240V 50/60Hz
Light Efficiency : >110m/W
Color Temperature : 3000K/4500K/6000K
Operating Temperature : -40℃ ±60℃
Warranty : 3years
Power Factor : >0.9
Color Rendering Index(Ra) : >70
Viewing Angle :
IP Grade : IP65
Material : Aluminium
Driver Brand : MOSO/Meanwell/Sosen
Urban roads and highways
Parking areas
Residential or industrial areas
Parks and commercial areas
Model 型號 |
Power 功率 |
Lamp 封裝 |
Luminous Flux 光通量 |
Packing(cm) 包裝尺寸 |
GW/N(kgs) 毛重/凈重 |
Installation height 安裝高度 |
---|---|---|---|---|---|---|
CY-LZY30W | 30W | SMD | 2800 | 41*17*11.5 | 1.8/1.44 | 4M |
CY-LZY60W | 60W | SMD | 5400 | 46.5*20*10 | 2.7/2.32 | 6M |
CY-LZY120W | 100W | SMD | 9500 | 54.5*27*10.5 | 4.8/4.24 | 8M |
