LED Chip Brand : philips/Bridgelux/
Input Volage : AC100-240V 50/60Hz
Light Efficiency : >110m/W
Color Temperature : 3000K/4500K/6000K
Operating Temperature : -40℃ ±60℃
Warranty : 3years
Power Factor :>0.9
Color Rendering Index(Ra) : >70
Viewing Angle :
IP Grade : IP65
Material : Aluminium
Driver Brand : MOSO/Meanwell/Sosen
Urban roads and highways
Parking areas
Residential or industrial areas
Parks and commercial areas
型號 |
功率 |
封裝 |
光通量 |
包裝尺寸 |
毛重/凈重 |
安裝高度 |
---|---|---|---|---|---|---|
CY-H263-60W | 60W | COB | 6000 | 300*300*200 | 6/5.2 | 5M |
CY-H345-100W | 100W | COB | 10000 | 400*400*300 | 7.5/6.7 | 5-8M |
CY-H380-240W | 240W | COB | 24000 | 450*450*350 | 13/11.5 | 12-15M |
CY-H501-360W | 360W | COB | 36000 | 550*550*400 | 20/18.5 | 20-30M |
