LED Chip Brand : philips/Bridgelux/
Input Volage : AC100-240V 50/60Hz
Light Efficiency : >110m/W
Color Temperature : 3000K/4500K/6000K
Operating Temperature : -40℃ ±60℃
Warranty : 3years
Power Factor : >0.9
Color Rendering Index(Ra) : >70
Viewing Angle :
IP Grade : IP65
Material : Aluminium
Driver Brand : MOSO/Meanwell/Sosen
Urban roads and highways
Parking areas
Residential or industrial areas
Parks and commercial areas
Model 型號 |
Power 功率 |
Lamp 封裝 |
Luminous Flux 光通量 |
Packing(cm) 包裝尺寸 |
GW/N(kgs) 毛重/凈重 |
Installation height 安裝高度 |
---|---|---|---|---|---|---|
CY-LZM80W | 80W | SMD | 9200 | 460×416×204 | 4.3/5.1 | 6-8M |
CY-LZM120W | 120W | SMD | 13800 | 500×416×204 | 6.3/7.3 | 8-9M |
CY-LZM200W | 200W | SMD | 23000 | 578×416×204 | 7.6/8.6 | 10-12M |
CY-LZM280W | 280W | SMD | 32200 | 656×416×204 | 7.5/8.6 | 12-15M |
