LED Chip Brand : philips/Bridgelux/
Input Volage : AC100-240V 50/60Hz
Light Efficiency : >110m/W
Color Temperature : 3000K/4500K/6000K
Operating Temperature : -40℃ ±60℃
Warranty : 3years
Power Factor : >0.9
Color Rendering Index(Ra) : >70
Viewing Angle :
IP Grade : IP65
Material : Aluminium
Driver Brand : MOSO/Meanwell/Sosen
Urban roads and highways
Parking areas
Residential or industrial areas
Parks and commercial areas
Model 型號 |
Power 功率 |
Lamp 封裝 |
Luminous Flux 光通量 |
Packing(cm) 包裝尺寸 |
GW/N(kgs) 毛重/凈重 |
Installation height 安裝高度 |
---|---|---|---|---|---|---|
CY-TZY150W | 150W | SMD | 16500 | 42.5x40.5x14.5cm | 4.68KG | 10M |
CY-TZY240W | 240W | SMD | 26400 | 42.5x40.5x14.5cm | 4.68KG | 15M |
CY-TZY360W | 360W | SMD | 39600 | 55.5x50x19.5cm | 11KG | 20-30M |
